• 600W pure sine wave inverter
  • Operating mode and fault indicators
  • Power saving mode reduces standby power
  • Up to 12 hours continuous use
  • Compact heavy duty extruded casing
  • USB charging socket for mobile devices
  • Optional multi-function LCD display (RINVLCD)
  • Optional battery sensor module (RINVCM)
  • Fully protected against overload, over temperature and low/high voltage
  • Suitable for 12V vehicles

Professional 600 watt pure sine wave inverter, converts 12 volt battery power into useful 230 volt AC mains power - ideal for remote applications such as service vehicles. Pure sine wave inverters provide an extremely pure output, which replicates the normal domestic mains supply. This makes them suitable for powering products not compatible with modified sine wave inverters, such as certain power tools, coffee machines, laser printers and sensitive electronics such as laptops and audio/visual equipment.

Highly efficient, running at 90% efficiency at 75% load, and with minimal footprint to reduce installation space. Includes a power saving mode to reduce battery drain when not in use. All models are fully protected against overload, over temperature and low/high voltages.

An additional LCD screen is also available, to provide power consumption information – essential for effective power management when working remotely. Also available is the RINVCM Current Sensor, which monitors the inverter's battery current, allowing indication of time remaining before battery is flat to help improve power management.

PowerSourcePure inverters are E-Marked and tested and certified to the relevant EMC and LVD Directives.

For Ring's full range of commercial inverters and accessories, click here

Description 600W Pure Sine Wave Inverter
Input Voltage Range 9.5V-16.5V (12V nom)
Input Current 59A (max)
Efficiency @ 75% load 0.9
No Load Current Draw <1.5A
Output Voltage 200/220/230/240V AC ±3%
Output Frequency 50/60Hz ±0.05%
Output Waveform Pure Sine Wave
Cont Power Rating (up to 12 hours) 600W
Peak Power Rating (up to 200ms) 1200W
Power Saving Mode Yes
Power Saving Mode Current <0.2A
Low Battery Alarm 10.0V-11.5V ±0.5V
Low Battery Shutdown 9.5V-11.0V ±0.5V
Thermal Protection 60° ±10°C
AC Mains Outlets UK: 1 x 13A 3-pin UK Euro: 1 x 10A 2-pin Shuko
USB Port 2.1A
LCD Display Panel No
Display Panel Port Yes
Current Sensor Port Yes
Comms Port Yes
Input Cable Gauge / Length 14mm² / 950mm
Approvals CE-LVD / RoHS / WEEE / E-Mark
RCD Trip Current N/A
Remote Control Port N/A
Product Dimensions (mm) 85 x 171 x 383
Weight (kg) 3.418
Case Quantity 4 x 1
