BATTERY

CURRENT SENSOR

Provides monitoring of inverter battery current
Allows indication of time remaining before battery is flat
Improves power management
Temperature compensation sensor

Current sensor monitors the current being taken from the battery and gives an accurate reading for how long power usage can be maintained. This can prevent power running out with no warning.

For Ring's full range of commercial inverters and accessories, click here

Related Products

RINVFRM

MULTI FUNCTION
LCD FRAME

RINVLCD

MULTI FUNCTION
LCD SCREEN

RINVWRC

PROFESSIONAL INVERTER
REMOTE CONTROL PANEL

Spec	RINVCM	RINVFRM	RINVLCD	RINVWRC
Input Voltage	12V DC (nominal)
Input/Output Current	500A (max)
Battery Cables Gauge / Length	2 x 38mm² / 30cm, 1 x 22mm² / 30cm
Data Cable Length	1m / 3m / 1.75m
Temp Sensor Cable Length	3m
+12V Power Cable Length	1.75m
Approvals	CE-EMC / RoHS / WEEE / E-Mark
Product Dimensions (mm)	40 x 120 x 91
Weight (kg)	0.976
Case Quantity	20 x 1

n/a

RoHS / WEEE

29 x 100 x 70

0.188

50 x 1

n/a

CE-EMC / RoHS / WEEE / E-Mark

37 x 100 x 70

0.232

50 x 1

n/a

CE-EMC / RoHS / WEEE / E-Mark

48 x 60 x 25

0.156
